Flamingo

  • Category: Surveillance UAV

Specification:

  • Dimensions: Length 5.18m, Wingspan 6.61m (Shoulder Wing Monoplane,twin boom).
  • Weight(s): Max. takeoff weight 245 kg, Payload 30~35 kg.
  • Powerplant: 50~60 hp, 4 cylinder, 2 stroke Gasoline Engine.
  • Electrical Power: 28V, 900W.

Performance:

  • Speed: 130 kph.
  • Endurance: 6~8 hr.
  • Ceiling: 12,000~15,000 ft.
  • Range: 200+ km.

Control:

  • Guidance/Tracking: Remote control/pre-programmed autonomous navigation.
  • Datalink: Real time double datalink.
  • Launch: Wheeled.
  • Recovery: Wheeled.
  • GCS: 2 console, truck mounted.
